The high DC approximately 2KV from a 230V AC supply in a voltage multiplier circuit can be built with diodes and capacitors in the form of a ladder network. The proposed system gives an overview of how to design a high voltage DC from a single phase AC. The circuit can be designed with a voltage multiplier, whose principle is to go on doubling the voltage for every stage.
